Description
Features
- Simultaneous display of pH(ORP) and Temp.
- Microprocessor controllers – Reliable Monitoring
- Simple calibration with sensor
- Upper & Lower limit setting – notification available
- Suitable for the field ( Wall, Panel and pipe installation IP65)
- Automatic temperature identification (PT1000, NTC30K)
- Auto temperature compensation & Notification for calibration
- 4~20mA , on/off control function provided
- Setting available interval of cleaning
- Solution-ground function to minimize sample interference
- RS485 communication & MODBUS
- Size : 96 x 96 x 145 mm
Specifications
|
Model |
HP960 |
HP960RS |
|
Measuring item |
pH / ORP / Temp. |
|
|
Range |
pH : -2.00~16.00 pH |
|
|
Resolution |
pH : 0.01 pH |
|
|
Accuracy |
pH : ±0.01 ± 1 digit |
|
|
Temp. |
-30.0~130.0 ℃ |
|
|
Temp. accuracy |
±0.2 °C ±1digit |
|
|
Temp. compensation |
Automatic temperature identification , Pt1000/NTC30K |
|
|
Calibration |
1~3 point |
|
|
Output |
Analog output x 2 |
Analog output x 1 Digital output x1 |
|
Communication |
x |
RS485 |
|
Contact output |
Contact output : relay ON/OFF, max. 240VAC 0.5A |
|
|
Washing setting |
ON : 0~9999 seconds / OFF : 0~999.9 hours |
|
|
Power output |
DC±12V |
|
|
Water proof |
IP 65 |
|
|
Temperature & |
0 ~ 50 ℃ / 5~85% |
|
|
Dimension |
96 X 96 X 145mm / 0.4 kg |
|
|
Power supply |
100 ~ 240VAC±10%, 50/60Hz |
|
