Description
Features
- Simultaneous display of Ion and Temp.
- Microprocessor controllers – Reliable Monitoring
- Simple calibration with sensor
- Upper & Lower limit setting – notification available
- Suitable for field ( Wall, Panel and pipe installation IP65)
- Automatic temperature identification (Pt 1000, NTC22K)
- Automatic temperature compensation & Calibration notification
- 4~20mA , on/off control function provided
- Setting available interval of cleaning
- Solution-ground function to minimize sample interference
- RS485 communication & MODBUS
- Size :144 x 144 x 115 mm
Specification
|
Model |
HI5000 |
HI5000RS |
|
Measuring item |
Ion / Temp. |
|
|
Range |
0.00 ~ 20000 ppm |
|
|
-2000.0 ~ 2000.0 mV |
||
|
Resolution |
1 / 0.1 / 0.01 ppm |
|
|
0.1 mV |
||
|
Accurracy |
±0.06% ±1 digit |
|
|
Temp. |
-10.0~110.0 ℃ |
|
|
Temp. accuracty |
±0.2 °C ±1digit |
|
|
Temp. compensation |
Pt1000/NTC30K |
|
|
Remark |
2 ~3 point or offset calibration |
|
|
Output |
Analog output 1 : Isolated DC 0/4~20mA corresponding to measurement max. load 500Ω |
|
|
Communication |
x |
RS485 |
|
Contact output |
Contact output : Relay ON/OFF, max. 240VAC 0.5A |
|
|
Washing setting |
ON : 0~9999 seconds / OFF : 0~999.9 hours |
|
|
Water proof |
IP 65 |
|
|
Temperature for use |
0 ~ 50 ℃ |
|
|
Dimension |
144 x 144 x 115 mm / 0.8 kg |
|
|
Power supply |
100 ~ 240VAC / ±10%, 50/60Hz |
|
